XVR CP 4004

5 MP XVR Lite

4 Channels and 1 HDD
Efficient H.265 compression technology
Encoding abilty up to 5 MP lite
5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP)

Onglets horizontaux

Descriptif

Model No.	CP 4004
system
Master chip	MC6630
AD chip	2830
RAM	2G
Compression format	H.265
operating system	Embedded Linux operating system
video
Input	4
Preview	4 x 5MN@25fps
Coding	4*5MN@12fps
Decoding	4*5MN@12fps
Channel mode	Support any channel mode combination (1080N analog + 1080P digital)
Signal type	Analog/AHD/CVI/TVI 2.0/TVI 3.0/Network
VGA output	1080P
BNC output	not supported
HDMI output	1080P
Audio
Audio Input	1
Audio output	1

Two-way intercom	support
Playback
Number of real-time recording channels	4-way non-real-time
Video mode	Timing, manual, motion detection
The number of simultaneous playback	4
Search mode	Point-in-time search, calendar search, event search, channel search
Backup
USB mobile hard disk, U disk	support
USB DVD burner	support
Format	H.26X、AVI
Remote access
Browser	Supports multiple web browsers
Client	Support VMS
APP	Support for iPhone, Android
Storage
HDD NO.	1
E-SATA	not support
Network
Network port	10 / 100 Mbps Ethernet (RJ-45)
Powerful network services	supporting DHCP, PPPOE, FTP, DNS, DDNS, NTP, UPNP, Email, etc.(Except WIFI and 3G\4G modules are not supported)), complete supporting facilities (WEB, client, SDK), easily achieve interconnection and interoperability.
General
Language	Simplified Chinese,Traditional Chinese, English, Polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian, Japanese, German, French, Portuguese, Turkic, Spanish, Italian, Hungarian, Romanian, korean, Dutch, Greek, Vietnamese,
remote control	support
power supply	DC 12V/2A ≤4W (Without Hard Disk)
Work Temperature	-10°C ~60°C
Working humidity	10% ~ 90% Humidity
Dimension(W×D×H)	25521245mm
Weight	1.5kg

Téléchargement

fiche technique (PDF / 479 Ko)
